eGTT35A-TPC-BLM-B0-H1-CS-V5 Display Module

eGTT35A-BLM-B0-H1-CS

The eGTT35A is an intelligent graphic lcd TFT display that features a full color resistive, or capacitive touchscreen. With the available - industry standard - communication protocols (serial RS232, TTL, I2C, RS422 and USB) communicating, controlling and interacting with the display is easily achieved.

Included features, like the piezo speaker and vibratory motor, provide tactile and audio feedback for a comfortable, confident user interaction. Additionally, the field updatable micro SD card stores font and bitmap files to liberate space and resources for use by the microcontroller, Arduino, or other HMI controller. Suitable for a wide range of applications, and with a resolution of 320 x 240, the eGTT35A is a complete display solution that will quickly become the bright fresh face of your machine or user interface.

Pair the eGTT series with our free software - GTT Designer - to design screens and user interactions quickly and easily. The software, which is compatible with all GTT displays, is a fully graphical, object-on, drag and drop suite with a library of built-in objects. Including: graphs, charts, buttons and animations. The interface was designed so no technical expertise is required to create a fully interactive user interface in minutes.

  • 16bit Color 3.5' 320 x 240 QVGA graphic TFT display
  • Available Interfaces: Serial RS232, TTL, I2C, RS422 and USB
  • Resistive or Capacitive Touch panel
  • 2 GB on-board memory for fonts, graphics and animations
  • 32MB of RAM
  • Two available voltage options: 5Vdc or 9-35Vdc
  • Programmable to display any language
  • Field upgradable firmware
  • Hardware flow control
  • Fast and easy development
  • Designed, supported and Made in CANADA.
  • Backed my Matrix Orbital`s decades of research and development.
  • GTT HMI/GUI Design Software

This is 320 x 240 intelligent Graphic LCD TFT display that features a full color resistive or capacitive touchscreen in serial RS232 protocol.

Software
GTT Developer Manual
GTT Protocol Manual
Cables
LCD Selection Guide
Keypad Selection Guide

Features:

Keypad25
GPO6
LCD TypeGraphic TFT Touch
PolarizerTransmissive
ModelA
ControllerLPC1788

Appearance:

Module Size98.00 mm(L)×78.00 mm(W)×19.53 mm(T)
Pixels320(Rows)×240(Cols)
Active Area70.08 mm(L)×52.56 mm(W)
Background ColorBlack
Text ColorFull Color

Interface:

Buffer4096 bytes Bytes
OtherPiezo Buzzer, Tactical Feedback

Electrical:

Standard Temperature0°C to 50°C
Extended Temp.(-E)-20°C to 70°C
Max Humidity0%
Supply Current275 mA
Backlight Current150 mA

Part No. Description Price
eGTT35A-TPN-BLM-B0-H1-CS-V5 3.5' 320x240 intelligent Graphic TFT display, Serial RS232 Interface, 5V Power. $80
eGTT35A-TPR-BLM-B0-H1-CS-V5 Resistive panel 3.5' Touch Screen 320x240 TFT, Serial RS232 Interface, 5V Power. $83
eGTT35A-TPN-BLM-B0-H1-CS-VPT 3.5' 320x240 intelligent Graphic TFT display, Serial RS232 Interface, 9-35V Power. $90
eGTT35A-TPC-BLM-B0-H1-CS-V5 Capacitive panel 3.5' Touch Screen 320x240 TFT, Serial RS232 Interface, 5V Power. $90
eGTT35A-TPR-BLM-B0-H1-CS-VPT Resistive panel 3.5' Touch Screen 320x240 TFT, Serial RS232 Interface, 9-35V Power. $93
eGTT35A-TPC-BLM-B0-H1-CS-VPT Capacitive panel 3.5' Touch Screen 320x240 TFT, Serial RS232 Interface, 9-35V Power. $100
